Generator Set Specifications
| Minimum Rating | 313 kVA / 250 kW |
| Maximum Rating | 344 kVA / 275 kW |
| Emissions/Fuel Strategy | Fuel Optimised |
| 60 Hz Prime | 313 kVA / 250 kW |
| 60 Hz Standby | 344 kVA / 275 kW |
| Frequency | 60 Hz |
| Speed | 1800 RPM |
| Voltage | 127-480 Volts |
P344-5
Minimum Rating
312.5 kVA / 250.0 kW
Maximum Rating
343.8 kVA / 275.0 kW
Emissions/Fuel Strategy
Standard reference conditions 25°C (77°F) Air Inlet Temp, 100m (328 ft) A.S.L. 30% relative humidity. Fuel consumption data at full load with diesel fuel with specific gravity of 0.85 and conforming to BS2869: 1998, Class A2.
View Product Downloads
Full Specifications
Engine Specifications
| Engine Model | Perkins® 1506A-E88TAG4 |
| Bore | 112.0 mm (4.4 in) |
| Stroke | 149.0 mm (5.9 in) |
| Governor Type | Electronic |
| Displacement | 8.8l (537.0 cu. in) |
| Compression Ratio | 16.1:1 |
Benefits & Features
Optional Equipment
Engine
- Air Cleaner
- Lube oil drain valve
- Engine filled with lubrication oil
- High Coolant Temperature Shutdown
- Low Oil Pressure Shutdown
Cooling
- Coolant Drain Valve
- Fan, Fan drive and battery charging Alternator drive fully guarded to meet EC Machinery Directive
- Cooling System filled with Coolant mix
- Radiator and Cooling Fan
Exhaust
- Exhaust stub pipe and gasket
Fuel
- 8 Hr Fuel Tank
- Fuel Fittings for Local and Remote Feed
Alternator
- FG Wilson
- SHUNT Excitation
- IP23 Protection
- Coastal Insulation Protection
Control Panel
- PowerWizard 1.1+
Mounting
- Base, Formed Steel with Single wall Fuel Tank
- Certified Base Mounted Lifting Eyes, and Rear Drag Eyelets
- Battery Tray and Cables
Standard Equipment
Exhaust
- Industrial, Residential, Critical Silencers
Alternator
- Quadrature Droop Kit
- Anti-Condensation Heater and Panel Circuitry (AH1)
Control Panels
- PowerWizard 2.1 Control Panel (PWT2.1)
- EasYgen 2500 control panel
Starting/Charging
- Calcium battery (Dry)
General
- Upgrade to Standard Set for “CE” Certification
- Compact Skid Base for Open Sets
- Sound attenuated, steel or galvanised enclosure
- Dual wall fuel tanks
