|Minimum Rating||150 kVA / 120 kW|
|Maximum Rating||187.5 kVA / 150.0 kW|
|Frequency||50 hz or 60 Hz|
|Speed||1500 or 1800 RPM|
|50 Hz Prime||150 kVA / 120 kW|
|50 Hz Standby||165.0 kVA / 132.0 kW|
|60 Hz Prime||168.8 kVA / 135.0 kW|
|60 Hz Standby||187.5 kVA / 150.0 kW|
|Emissions/Fuel Strategy||Fuel Optimised|
|Engine Model||Perkins® 1106A-70TAG2|
|Bore||105 mm (4.1 in)|
|Stroke||135.0 mm (5.3 in)|
|Displacement||7.0l (427.8 cu. in)|
Benefiting from a choice of leading alternators, the range incorporates the Marelli alternator as standard across three phase models.
The FG Wilson DCP range allows you to monitor and control your generator set with ease, providing important diagnostic information whilst ensuring your unit operates within safe parameters. FG Wilson DCP digital control panels, provide simple, intuitive menu navigation and control of your generator set operations. Key information is displayed via the LCD screen and LED’s using universally recognised symbols, eliminating the need for complex instructions or language settings.
Prime Rating These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power. There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hour in 12 hours. Standby Rating These ratings are applicable for supplying continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted on these ratings. The alternator on this model is peak continuous rated (as defined in ISO 8528-3). Standard Reference Conditions Note: Standard reference conditions 25°C (77°F) Air Inlet Temp, 100m (328 ft) A.S.L. 30% relative humidity. Fuel consumption data at full load with diesel fuel with specific gravity of 0.85 and conforming to BS2869: 1998, Class A2.
Fully prototype tested with certified torsional vibration analysis available
FG Wilson manufactures product in the following locations: Northern Ireland • Brazil • China • India • USA With headquarters in Northern Ireland, FG Wilson operates through a Global Dealer Network.
